# bj

Estimate Box-Jenkins polynomial model using time-domain data

## Syntax

## Description

Box-Jenkins (BJ) models are a special configuration of polynomial models that provide completely independent parameterization for the dynamics and noise using rational polynomial functions. BJ models, which are always discrete-time models, can be estimated only from time-domain data. Use BJ models when the noise is primarily a measurement disturbance rather than an input disturbance. The BJ structure provides additional flexibility for modeling the noise.

### Estimate Box-Jenkins Model

estimates a Box-Jenkins polynomial model `sys`

= bj(`tt`

,```
[nb
nc nd nf nk]
```

)`sys`

using the data
contained in the variables of timetable `tt`

. The software
uses the first *Nu* variables as inputs and the next
*Ny* variables as outputs, where *Nu* and
*Ny* are determined from the dimensions of the specified
polynomial orders.

`sys`

is represented by the equation

$$y(t)={\displaystyle \sum _{i=1}^{nu}\frac{{B}_{i}(q)}{{F}_{i}(q)}{u}_{i}\left(t-n{k}_{i}\right)}+\frac{C(q)}{D(q)}e(t)$$

Here, *y*(*t*) is the
output, *u*(*t*) is the input, and
*e*(*t*) is the error.

The components of `[nb nc nd nf nk]`

define the orders of
the polynomials used for estimation. For more information about the Box-Jenkins
model structure, see Box-Jenkins Model Structure.

To select specific input and output channels from `tt`

, use
name-value syntax to set `'InputName'`

and
`'OutputName'`

to the corresponding timetable variable
names.

uses the time-domain input and output signals in the comma-separated matrices
`sys`

= bj(`u`

,`y`

,`[nb nc nd nf nk]`

)`u`

,`y`

. The software assumes that the
data sample time is 1 second. To change the sample time, set
`Ts`

using name-value syntax.

uses the time-domain data in the `sys`

= bj(`data`

,`[nb nc nd nf nk]`

)`iddata`

object
`data`

. Use this syntax especially when you want to take
advantage of the additional information, such as data sample time or experiment
labeling, that data objects provide.

specifies model structure attributes using additional options specified by one
or more name-value arguments. You can use this syntax with any of the previous
input-argument combinations.`sys`

= bj(___, `Name,Value`

)

### Configure Initial Parameters

### Specify Additional Estimation Options

### Return Estimated Initial Conditions

`[`

returns the estimated initial conditions as an `sys`

,`ic`

] = bj(___)`initialCondition`

object. Use this syntax if you plan to simulate
or predict the model response using the same estimation input data and then
compare the response with the same estimation output data. Incorporating the
initial conditions yields a better match during the first part of the
simulation.

## Examples

## Input Arguments

## Output Arguments

## More About

## Alternatives

To estimate a continuous-time model, use:

## References

[1] Ljung,
L. *System Identification: Theory for the User*, Upper Saddle River, NJ,
Prentice-Hall PTR, 1999.

## Version History

**Introduced before R2006a**
