stateflow

Open Stateflow block library and create Simulink model that contains an empty chart

Syntax

stateflow

Description

stateflow creates an untitled Simulink^® model that contains an empty Stateflow^® chart. The function also opens the Stateflow block library. From this library, you can drag Stateflow blocks into models.

Tips

• To only create a Simulink model that contains an empty Stateflow block, use the sfnew function.

• To only open the Stateflow block library, use the sflib function.

• To create a standalone chart that you can execute as a MATLAB^® object, open the Stateflow editor by using the edit function. For example, at the MATLAB Command Window, enter:

  edit chart.sfx

  For more information, see Create Stateflow Charts for Execution as MATLAB Objects.

Version History

Introduced before R2006a

R2019b: Opening Stateflow

The behavior of the stateflow function will change in a future release. Use sfnew and sflib instead.
