Motor Parameter Estimation and Plant Modeling
Compute estimated motor parameters and create plant model
Use the parameter estimation tool to estimate the motor parameters and create a plant model that accurately depicts the hardware that interfaces with the motor.
Note
The blocks listed here are compliant with the MISRA C™ guidelines.
Blocks
Apps
Motor Hardware Configurator | Configure and validate motor and control hardware (Since R2024b) |
Motor Parameter Estimator | Estimate electrical and mechanical parameters of motor connected to control hardware (Since R2024b) |
Topics
- Estimate Motor Parameters Using Motor Control Blockset Parameter Estimation Tool
Estimate motor parameters by using parameter estimation feature in Motor Control Blockset™.
- Creating Plant Model Using Motor Control Blockset
Create and verify the plant model.
- Estimate Control Gains and Use Utility Functions
Perform control parameter tuning for speed and torque control subsystems.
