R2022a at a Glance



Discover What's New

Get more out of MATLAB and Simulink by downloading the latest release.

Video Player is loading.
Current Time 0:00
Duration 0:00
Loaded: 0%
Stream Type LIVE
Remaining Time 0:00

1x
  • Chapters
  • descriptions off, selected
  • captions off, selected
      Video length is 2:38

      R2022a Release Highlights

      New Products

      Major Updates

      • Econometrics Toolbox – Conduct cointegration tests and fit multivariate time series models interactively in the Econometric Modeler app
      • MATLAB Compiler SDK – Publish a MATLAB function as a Docker container microservice
      • MATLAB Production Server – Map custom request URLs to deployed MATLAB functions, serve static content, and customize request headers
      • Polyspace Access – Identify coding defects, review static analysis results, and monitor software quality metrics
      • Requirements Toolbox – Link requirements to MATLAB code and tests; formalize and validate requirements
      • Risk Management Toolbox – Perform lifetime expected credit loss (ECL) computations at the individual asset or portfolio level
      • Robotics System Toolbox – Construct cuboid scenarios and simulate sensor readings for robotics applications
      • Signal Processing Toolbox – AI workflows: pre-process, extract features, and label signals
      • Simulink Check – Author custom edit-time checks and justify Model Advisor violations
      • Simulink Real-Time – Linux platform support for development computer

      Release Details by Product

      MATLAB Product Family

      MATLAB

      • 3 New Apps: Data Cleaner, Hardware Manager, Code Compatibility Analyzer
      • pcode: Use new pcode file format with stronger obfuscation
      • Python: Use simpler keyword passing with name=value syntax, and editor support for Python code
      • Graphics: Create animated GIF files; pass tables directly to plot, plot3, polarplot, and other line plotting functions
      • App Building: Create custom UI components with App Designer
      • Live Editor: Develop your own Live Editor tasks
      • N-D Array Math: tensorprod, pagemldivide, pagemrdivide, and pageinv
      • Parquet Files: Use conditional filtering (Predicate Pushdown) with rowfilter; support for reading and writing of row groups and nested data structures

      AI, Data Science, and Statistics

      Deep Learning Toolbox

      • Model Pruning: Create compressed versions of models that consume less computational resources
      • MATLAB Deep Learning Model Hub: Discover and use pretrained deep learning models
      • Deployment of Imported Models: Generate code for additional Keras and ONNX built-in layers
      • Experiment Manager Batch Experiments: Run multiple experiments simultaneously on a remote cluster (requires MATLAB Parallel Server)
      • 1D Convolutional Networks: Create and train networks with 1-D transposed convolution for sequence and time series data

      Statistics and Machine Learning Toolbox

      • Machine Learning Apps: Save and resume sessions, rank and select features by importance, and reserve data for testing
      • Incremental Machine Learning: Perform drift detection on streaming data; train kernel and multi-class linear models
      • Deployment: Generate C/C++ code for inference with shallow neural nets
      •  Simulink: Simulink block for Gaussian process regression

      Curve Fitting Toolbox

      • Curve Fitter app: Use new toolstrip design for improved usability; select fitting and validation data from MATLAB table data types

      Control Systems

      Model Predictive Control Toolbox

      • MISRA C 2012: Implement MISRA C:2012-compliant controllers with linear MPC and ADAS blocks in Simulink

      System Identification Toolbox

      • Nonlinear System Identification: Create Hammerstein-Wiener models that use regression functions based on machine learning algorithms

      Simulink Design Optimization

      • Surrogate Optimization Solver in Response Optimizer and Parameter Estimator Apps: Speed up time-consuming optimization problems

      Reinforcement Learning Toolbox

      • Model-Based Policy Optimization Agent: Use a model of the environment to improve sample efficiency and exploration
      • Multi-Agent Reinforcement Learning: Train multiple agents in a centralized manner for more efficient exploration and learning

      Predictive Maintenance Toolbox

      • Deployment: Generate C/C++ code for RUL similarity models, rotating machinery metrics, and nonlinear signal features
      • Diagnostic Feature Designer: Extract stationary time series features from signal data

      Math and Optimization

      Optimization Toolbox

      • Problem-Based Optimize Live Editor Task: Solve optimization problems and systems of equations using a visual interface

      Global Optimization Toolbox

      • Problem-Based Optimize Live Editor Task: Solve global and multiobjective optimization problems using a visual interface

      Symbolic Math Toolbox

      • Symbolic Matrix Functions: Perform parameter-dependent linear algebra calculations in compact matrix notation

      Partial Differential Equation Toolbox

      • Electromagnetic Analysis: Solve time-harmonic wave scattering and transmission problems using a finite element method
      • Thermal Reduced Order Models: Approximate dynamic characteristics of a thermal model for faster execution (e.g., for batteries and CPUs)

      Application Deployment

      MATLAB Compiler SDK

      • Microservice Integration: Create a microservice Docker image using the compiler.package.microserviceDockerImage function

      MATLAB Production Server

      • Web Request Handlers: Support for custom URL routes and request payloads

      Code Generation

      AUTOSAR Blockset

      • Adaptive AUTOSAR: Use ara::com methods and ara::com with service-oriented communication support events
      • Classic AUTOSAR: Simulate basic software component event failure and recovery, including Release 19-11

      DDS Blockset

      • Support for RTI Connext Micro communication middleware

      Fixed-Point Designer

      • Estimate design costs of data memory consumption and operator counts in generated code

      MATLAB Coder and GPU Coder

      • Generate generic C/C++ code for more deep learning layers
      • Improve performance for deep learning network layers, including SIMD
      • Support for additional TensorFlow-Keras and ONNX built-in layers
      • Incorporate pretrained TensorFlow Lite models for simulation and code generation

      Simulink Coder

      • Specify tunable parameters for protected models

      Embedded Coder

      • Use deployment types to simplify configuration of top and reference model interfaces
      • Improve compliance for MISRA C:2012, MISRA C++:2008, and AUTOSAR C++14
      • Profile stack usage to assess memory consumption

      Simulink Product Family

      Simulink

      • Streamline masking workflows with new mask editor
      • Integrate custom C++ class with C Function block
      • Improve simulation performance by using local solvers in referenced models
      • Simulink Fundamentals training course

      Simulink Compiler

      • App Creation: Generate a configurable MATLAB UI from a Simulink model without writing code
      • FMU Export: Package files and folders as well as protected models into a standalone FMU

      Simulink Report Generator

      • Summarize Simulink model contents in a table object
      • Include user notes in web views

      Event-Based Modeling

      Stateflow

      • Integration of Stateflow breakpoints in the Simulink Breakpoints List pane
      • Improved workflows in creating atomic subcharts with entry and exit junctions
      • String datatypes now supported in State Transition Table and Truth Table blocks

      Physical Modeling

      Simscape Electrical

      • Model hydrogen production with new Electrolyzer block
      • Parameterize solar panels by selecting from more than 250 manufacturer-specific datasets
      • Expanded motor library and features, including switched-reluctance machines, PMSM, and detailed iron losses

      Real-Time Simulation and Testing

      Simulink Real-Time

      • Install and use Simulink Real-Time on Linux development computers
      • Automatically create an App Designer instrument panel from a model or real-time application
      • Improved test automation with third-party tools with ASAM XIL API classes and methods for MAPort read/write, SignalFactory, SignalGeneratorFactory, and SignalGenerator

      Systems Engineering

      System Composer

      • Client-Server Interfaces: Model distributed software service architectures
      • Use subsystem references to add reusable Simulink and Simscape behaviors to components
      • Compare two versions of an architecture model using the Comparison Tool

      Verification, Validation, and Test

      Requirements Toolbox

      • Author, link, and validate requirements within MATLAB
      • Trace requirements for test cases created in MATLAB Unit Test
      • Formalize requirements with logical expressions using the Requirements Table block
      • Track requirements impacted by changes in test cases

      Simulink Check

      • Author custom checks that run at edit-time
      • Justify and hide check violations
      • Include System Composer models in the Model Testing Dashboard artifact hierarchy
      • Refactor similar clones anywhere in the model
      • Debug equivalence test failures using Model Slicer

      Simulink Test

      • New logical and temporal assessment functions and classes
      • Observer support for messages

      Simulink Design Verifier

      • Analyze requirements authored in a Requirements Table to check for consistency and completeness

      Signal Processing

      Signal Processing Toolbox

      • AI Workflows: Preprocess, extract features, and label signals
      • Generate C/C++ code for more than 200 toolbox functions
      • GPU support for feature extraction, spectral analysis, spectral measurements, and transforms

      DSP Toolbox

      • Spectrum Analyzer with better responsiveness and toolstrip interface for analysis, estimation, and measurement parameters

      Wavelet Toolbox

      • Visualize scalogram with Wavelet Time-Frequency Analyzer app

      Audio Toolbox

      • New examples for AI, room acoustics, and electroacoustic modeling

      Radar

      Radar Toolbox

      • Model land and sea surface clutter and reflectivity

      Mapping Toolbox

      • Create custom basemaps for offline use
      • Capture image from basemap with georeferencing information

      Image Processing and Computer Vision

      Computer Vision Toolbox

      • New image data type for image processing and computer vision in Simulink

      Lidar Toolbox

      • Lidar Sensor Model: Simulate lidar sensors and generate point cloud data

      FPGA, ASIC, and SoC Development

      HDL Coder

      • Generate IP core for Xilinx Versal devices
      • Use reference design workflow for Microsemi Libero SoC

      Deep Learning HDL Toolbox

      • Network custom layer creation, registration, validation, and deployment

      DSP HDL Toolbox

      • New Product: Model hardware implementations of DSP algorithms and generate HDL (using HDL Coder)

      Vision HDL Toolbox

      • Support multipixel per clock for Histogram and Bilateral Filter blocks

      Wireless HDL Toolbox

      • Use DVB-S2 receiver reference application

      HDL Verifier

      • Use Vivado simulator for cosimulating an HDL design with a Simulink or MATLAB test bench
      • Use hardware buffering to improve FPGA-in-the-loop simulation performance

      Test and Measurement

      Industrial Communication Toolbox

      • New Product: Exchange data over OPC UA, Modbus, MQTT, and other industrial protocols
      • Access plant and manufacturing data directly from OSIsoft PI servers

      Data Acquisition Toolbox

      • TDMS File Support: Read data from an individual NI TDMS format file or use datastore to read a collection of TDMS files

      Instrument Control Toolbox

      • UDP Explorer App: Create a UDP socket and communicate over networks using UDP protocol
      • New Instrument Driver Interface: Connect to instruments using IVI and VXIplug&play drivers

      Vehicle Network Toolbox

      • MDF File Support: Create MDF files and write to MDF files directly from MATLAB

      Image Acquisition Toolbox

      • Image Acquisition Explorer App: Preview live video data from your image acquisition hardware and configure device-specific properties and acquisition settings

      Wireless Communications

      Communications Toolbox

      • Wireless Communications Onramp: Learn the basics of simulating a wireless communications link in MATLAB

      Bluetooth Toolbox

      • New Product: Simulate, analyze, and test Bluetooth communications systems

      Wireless Testbench

      • New Product: Explore and test wireless reference applications in real time on SDR hardware

      Autonomous Systems

      Automated Driving Toolbox

      • Cosimulate scenarios in RoadRunner with actors modeled in MATLAB and Simulink

      Robotics System Toolbox

      • Robot Scenarios and Sensor Models: Construct cuboid scenario and simulate sensor readings for robotics applications
      • Inverse Kinematics Designer App: Visualize and tune inverse kinematics solvers and create configurations

      UAV Toolbox

      • Hardware in the Loop: Enable hardware-in-the-loop (HIL) simulation with Pixhawk Autopilot and Simulink plant model
      • UAV Scenario Designer App: Design and visualize UAV simulation scenarios interactively

      RoadRunner Scenario

      • New Product: Create and play back scenarios for automated driving simulation

      Aerospace

      Aerospace Blockset

      • 3D Simulation: Supports custom meshes and aircraft lighting in Simulation 3D Aircraft block

      Computational Finance

      Financial Instruments Toolbox

      • Instrument Pricing: Model trinomial trees with finpricer
      • Equity Instruments: Calculate rates and pricing for commodity futures, equity index futures, and FX futures
      • Live Task: Calibrate an option pricing model interactively

      Econometrics Toolbox

      • Conduct cointegration tests and fit multivariate time series models interactively in the Econometrics Modeler app
      • Bayesian State-Space Models: Analyze posterior distributions of random parameters in multivariate linear state-space models

      Risk Management Toolbox

      • Lifetime Credit Risk Analysis: Calculate lifetime expected credit loss
      • Fairness in Credit Scoring Example: Calculate fairness metrics and detect bias at the data and model level

      Financial Toolbox

      • Perform Quasi-Monte Carlo simulation
      • Portfolio Management: Manage a risk parity portfolio
      • Backtesting Framework Example: Backtest with deep learning strategies

      Code Verification

      Polyspace Access

      • New web dashboard for improved user experience
      • Manage Polyspace Access projects programmatically
      • Visual Studio Code plug-in with new views for configuration, results, baseline, and mass findings justification

      Polyspace Bug Finder and Polyspace Bug Finder Server

      • Improve analysis time by using incremental compilation
      • Support 1,216 C/C++, MISRA C++, CERT-C++, CWE, and AUTOSAR C++ rules with 46 new checks

      Automotive

      AUTOSAR Blockset

      • Adaptive AUTOSAR: Use ara::com methods and ara::com events with service-oriented communication support
      • Classic AUTOSAR: Simulate basic software component event failure and recovery, including Release 19-11

      Model-Based Calibration Toolbox

      • Battery Calibration: Characterize an Equivalent Circuit Battery
      • Transient Calibration: Get faster optimization for Simulink models with first-order transient systems

      Powertrain Blockset

      • Use Virtual Vehicle Composer app to configure and build full vehicle models, including component sizing, fuel economy, and drive cycle tracking
      • Motor Dynamometer Reference Application: Resize and evaluate electric motors and controllers

      Vehicle Dynamics Blockset

      • Use Virtual Vehicle Composer app to configure and build full vehicle models, including ride-handling analysis and Unreal Engine visualization
      • Use suspension blocks to implement kinematics and compliance test characteristics
