Create spatial transformation structure (`TFORM`

)

`maketform`

is not recommended. Use `fitgeotrans`

, `affine2d`

, `affine3d`

, or `projective2d`

instead.

`T = maketform('affine',A)`

`T = maketform('affine',U,X)`

`T = maketform('projective',A)`

`T = maketform('projective',U,X)`

`T = maketform('custom',NDIMS_IN,NDIMS_OUT,FORWARD_FCN,INVERSE_FCN,TDATA)`

`T = maketform('box',tsize,LOW,HIGH)`

`T = maketform('box',INBOUNDS, OUTBOUNDS)`

`T = maketform('composite',T1,T2,...,TL)`

`T = maketform('composite', [T1 T2 ... TL])`

creates
a multidimensional spatial transformation structure`T`

= maketform('affine',`A`

)`T`

for
an N-dimensional affine transformation. `A`

is a
nonsingular real (N+1)-by-(N+1) or (N+1)-by-N matrix. If `A`

is
(N+1)-by-(N+1), the last column of `A`

must be `[zeros(N,1);1]`

.
Otherwise, `A`

is augmented automatically, such that
its last column is `[zeros(N,1);1]`

. The matrix `A`

defines
a forward transformation such that `tformfwd(U,T)`

,
where `U`

is a 1-by-N vector, returns a 1-by-N vector `X`

,
such that `X = U * A(1:N,1:N) + A(N+1,1:N)`

. `T`

has
both forward and inverse transformations.

A spatial transformation structure (called a `TFORM`

struct)
that can be used with the `tformfwd`

, `tforminv`

, `fliptform`

, `imtransform`

,
or `tformarray`

functions.

creates
a `T`

= maketform('projective',`A`

)`TFORM`

struct for an N-dimensional projective
transformation. `A`

is a nonsingular real (N+1)-by-(N+1)
matrix. `A(N+1,N+1)`

cannot be 0. The matrix `A`

defines
a forward transformation such that `tformfwd(U,T)`

,
where `U`

is a 1-by-N vector, returns a 1-by-N vector `X`

,
such that `X = W(1:N)/W(N+1)`

, where ```
W =
[U 1] * A
```

. The transformation structure `T`

has
both forward and inverse transformations.

creates
a custom `T`

= maketform('custom',`NDIMS_IN,NDIMS_OUT`

,`FORWARD_FCN,INVERSE_FCN`

,`TDATA`

)`TFORM`

struct `T`

based
on user-provided function handles and parameters. `NDIMS_IN`

and `NDIMS_OUT`

are
the numbers of input and output dimensions. `FORWARD_FCN`

and `INVERSE_FCN`

are
function handles to forward and inverse functions. The forward function
must support the following syntax: `X = FORWARD_FCN(U,T)`

.
The inverse function must support the following syntax: ```
U
= INVERSE_FCN(X,T)
```

. In these syntaxes, `U`

is
a `P`

-by-`NDIMS_IN`

matrix whose
rows are points in the transformation input space. `X`

is
a `P`

-by-`NDIMS_OUT`

matrix whose
rows are points in the transformation output space. The `TDATA`

argument
can be any MATLAB^{®} array and is typically used to store parameters
of the custom transformation. It is accessible to `FORWARD_FCN`

and `INVERSE_FCN`

via
the `tdata`

field of `T`

. Either `FORWARD_FCN`

or `INVERSE_FCN`

can
be empty, although at least `INVERSE_FCN`

must be
defined to use `T`

with `tformarray`

or `imtransform`

.

or`T`

= maketform('box',`tsize`

,`LOW,HIGH`

)

`T = maketform('box',INBOUNDS, OUTBOUNDS)`

builds
an N-dimensional affine `TFORM`

struct `T`

.
The `tsize`

argument is an N-element vector of positive
integers. `LOW`

and `HIGH`

are also
N-element vectors. The transformation maps an input box defined by
the opposite corners `ones(1,N)`

and `tsize`

,
or by corners `INBOUNDS(1,:)`

and `INBOUND(2,:)`

,
to an output box defined by the opposite corners `LOW`

and `HIGH`

or `OUTBOUNDS(1,:)`

and `OUTBOUNDS(2,:)`

. `LOW(K)`

and `HIGH(K)`

must
be different unless `tsize(K)`

is 1, in which case
the affine scale factor along the Kth dimension is assumed to be 1.0.
Similarly, `INBOUNDS(1,K)`

and `INBOUNDS(2,K)`

must
be different unless `OUTBOUNDS(1,K)`

and `OUTBOUNDS(2,K)`

are
the same, and conversely. The `'box'`

`TFORM`

is
typically used to register the row and column subscripts of an image
or array to some world coordinate system.

or`T`

= maketform('composite',`T1,T2,...,TL`

)

`T = maketform('composite', [T1 T2 ... TL])`

builds
a `TFORM`

struct `T`

whose forward
and inverse functions are the functional compositions of the forward
and inverse functions of `T1, T2, ..., TL`

.

The inputs `T1, T2, ..., TL`

are ordered just
as they would be when using the standard notation for function composition: ```
T
= T1
```

$$\circ $$ `T2`

$$\circ $$ ... $$\circ $$ `TL`

and note
also that composition is associative, but not commutative. This means
that to apply `T`

to the input `U`

,
one must apply `TL`

first and `T1`

last.
Thus if `L = 3`

, for example, then `tformfwd(U,T)`

is
the same as `tformfwd(tformfwd(tformfwd(U,T3),T2),T1)`

.
The components `T1`

through `TL`

must
be compatible in terms of the numbers of input and output dimensions. `T`

has
a defined forward transform function only if all the component transforms
have defined forward transform functions. `T`

has
a defined inverse transform function only if all the component functions
have defined inverse transform functions.

An affine or projective transformation can also be expressed like this equation, for a 3-by-2

`A`

:[X Y]' = A' * [U V 1] '

Or, like this equation, for a 3-by-3

`A`

:[X Y 1]' = A' * [U V 1]'
