Complex PartialSystolic Qless QR Decomposition
Qless QR decomposition for complexvalued matrices
 Library:
FixedPoint Designer HDL Support / Matrices and Linear Algebra / Matrix Factorizations
Description
The Complex PartialSystolic Qless QR Decomposition block uses QR decomposition to compute the economy size uppertriangular R factor of the QR decomposition A = QR, where A is a complexvalued matrix, without computing Q. The solution to A'Ax = B is x = R\R'\b.
When Regularization parameter is nonzero, the Complex PartialSystolic Qless QR Decomposition block computes the uppertriangular factor R of the economy size QR decomposition of $$\left[\begin{array}{c}\lambda {I}_{n}\\ A\end{array}\right]$$ where λ is the regularization parameter.
Ports
Input
A(i,:)
— Rows of matrix A
vector
Rows of matrix A, specified as a vector. A is an mbyn matrix where m ≥ 2 and n ≥ 2. If B is single or double, A must be the same data type as B. If A is a fixedpoint data type, A must be signed, use binarypoint scaling, and have the same word length as B. Slopebias representation is not supported for fixedpoint data types.
Data Types: single
 double
 fixed point
Complex Number Support: Yes
validIn
— Whether inputs are valid
Boolean
scalar
Whether inputs are valid, specified as a Boolean scalar. This control signal
indicates when the data at the A(i,:)
input port is valid. When
this value is 1 (true
) and the value at ready
is 1 (true
), the block captures the values at the
A(i,:)
input port. When this value is 0
(false
), the block ignores the input samples.
After sending a true
validIn
signal, there may be some delay before
ready
is set to false
. To ensure all data is
processed, you must wait until ready
is set to
false
before sending another true
validIn
signal.
Data Types: Boolean
restart
— Whether to clear internal states
Boolean
scalar
Whether to clear internal states, specified as a Boolean scalar. When this value
is 1 (true
), the block stops the current calculation and clears all
internal states. When this value is 0 (false
) and the
validIn
value is 1 (true
), the block begins
a new subframe.
Data Types: Boolean
Output
R
— Matrix R
scalar  vector
Economy size QR decomposition matrix R, returned as a scalar or vector. R is an upper triangular matrix. R has the same data type as A.
Data Types: single
 double
 fixed point
validOut
— Whether output data is valid
Boolean
scalar
Whether the output data is valid, specified as a Boolean scalar. This control
signal indicates when the data at output port R
is valid. When
this value is 1 (true
), the block has successfully computed the
matrix R. When this value is 0 (false
), the
output data is not valid.
Data Types: Boolean
ready
— Whether block is ready
Boolean
scalar
Whether the block is ready, returned as a Boolean scalar. This control signal
indicates when the block is ready for new input data. When this value is
1
(true
) and the validIn
value is 1
(true
), the block accepts input data
in the next time step. When this value is 0
(false
), the block ignores input data in the next time
step.
After sending a true
validIn
signal, there may be some delay before
ready
is set to false
. To ensure all data is
processed, you must wait until ready
is set to
false
before sending another true
validIn
signal.
Data Types: Boolean
Parameters
Number of rows in matrix A
— Number of rows in input matrix A
4
(default)  positive integervalued scalar
Number of rows in input matrix A, specified as a positive integervalued scalar.
Programmatic Use
Block Parameter:
m
Type: character vector
Values: positive integervalued scalar
Default:
4
Number of columns in matrix A
— Number of columns in input matrix A
4
(default)  positive integervalued scalar
Number of columns in input matrix A, specified as a positive integervalued scalar.
Programmatic Use
Block Parameter:
n
Type: character vector
Values: positive integervalued scalar
Default:
4
Regularization parameter
— Regularization parameter
0 (default)  real nonnegative scalar
Regularization parameter, specified as a nonnegative scalar. Small, positive values of the regularization parameter can improve the conditioning of the problem and reduce the variance of the estimates. While biased, the reduced variance of the estimate often results in a smaller mean squared error when compared to leastsquares estimates.
Programmatic Use
Block Parameter:
regularizationParameter
Type: character vector
Values: real nonnegative scalar
Default:
0
Algorithms
Choosing the Implementation Method
Partialsystolic implementations prioritize speed of computations over space constraints, while burst implementations prioritize space constraints at the expense of speed of the operations. The following table illustrates the tradeoffs between the implementations available for matrix decompositions and solving systems of linear equations.
Implementation  Ready  Latency  Area  Sample block or example

Systolic  C  O(n)  O(mn^{2})  Implement HardwareEfficient QR Decomposition Using CORDIC in a Systolic Array
PartialSystolic  C  O(m)  O(n^{2})
PartialSystolic with Forgetting Factor  C  O(n)  O(n^{2})  FixedPoint HDLOptimized MinimumVariance DistortionlessResponse (MVDR) Beamformer
Burst  O(n)  O(mn^{2})  O(n)
Where C is a constant proportional to the word length of the data, m is the number of rows in matrix A, and n is the number of columns in matrix A.
Block Timing
The following table provides details on the timing for the QR decomposition blocks.
Block  validIn to ready (c cycles)  validIn to validOut (v cycles)

Real PartialSystolic QR Decomposition  c = w + 8  v = c(m + n  1)
Complex PartialSystolic QR Decomposition  c = 2w + 15  v = c(m + n  1)
Real PartialSystolic Qless QR Decomposition  c = w + 8  v = c(m + n  1)
Complex PartialSystolic Qless QR Decomposition  c = 2w + 15  v = c(m + n  1)
Real PartialSystolic Qless QR Decomposition with Forgetting Factor  c = w + 8  v = c(2n  1)
Complex PartialSystolic Qless QR Decomposition with Forgetting Factor  c = 2w + 15  v = c(2n  1)
In the table, m represents the number of rows in matrix A, and n is the number of columns in matrix A. w represents the word length of A.
If the data type of A is fixed point, then w is the word length.
If the data type of A is double, then w is 53.
If the data type of A is single, then w is 24.
Extended Capabilities
C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.
Slopebias representation is not supported for fixedpoint data types.
HDL Code Generation
Generate Verilog and VHDL code for FPGA and ASIC designs using HDL Coder™.
HDL Coder™ provides additional configuration options that affect HDL implementation and synthesized logic.
This block has a single, default HDL architecture.
General

ConstrainedOutputPipeline  Number of registers to place at
the outputs by moving existing delays within your design. Distributed
pipelining does not redistribute these registers. The default is

InputPipeline  Number of input pipeline stages
to insert in the generated code. Distributed pipelining and constrained
output pipelining can move these registers. The default is

OutputPipeline  Number of output pipeline stages
to insert in the generated code. Distributed pipelining and constrained
output pipelining can move these registers. The default is

Supports fixedpoint data types only.
FixedPoint Conversion
Design and simulate fixedpoint systems using FixedPoint Designer™.
