With Simulink®, you can interactively simulate your system model and view the results on scopes and graphical displays. For simulation of continuous, discrete, and mixed-signal systems, you can choose from a range of fixed-step and variable-step solvers. Solvers are integration algorithms that compute system dynamics over time.
The integration of Simulink and MATLAB® enables you to run unattended batch simulations of your Simulink models using MATLAB commands.
- Prepare Model Inputs and Outputs
Define external interfaces for input data and control signals, define output signals for viewing and recording simulation results
- Configure Simulation Conditions
Select solver, set initial conditions, pick input data set, set step size
- Run Simulations
Simulate models interactively or in batch mode, create repeatable simulations using the model operating point, run Monte Carlo simulations
- View and Analyze Simulation Results
View data during simulation, analyze simulation data, save simulation and analysis results
- Test and Debug Simulations
Manage and diagnose simulation errors, set breakpoints, step through simulation time steps and block execution
- Optimize Performance
Optimize performance for specific goals, accelerate simulation speed and design efficient models
