FMU Importing

Optionally use a functional mockup unit (FMU) block to bring third-party functionality into Simulink®.

The FMU block lets you import your applications, contained in FMUs, into Simulink. This block has two modes to integrate FMUs that implement:

  • An FMI co-simulation interface. These FMUs contain local solvers.

  • An FMI model exchange interface. These FMUs do not contain local solvers.

Blocks

FMUInclude Functional Mockup Unit (FMU) in model

Topics

Import FMUs

Use the FMU block to import Functional Mockup Units (FMUs) into Simulink.

Implement an FMU Block

Implement a block and assign a functional mockup unit (FMU) to it.

Featured Examples
