Event Scheduling and Interrupt Handling

Schedule events and handle hardware interrupts to address real-time tasks with Arduino

Improve system responsiveness to real-time tasks and events using external and hardware interrupts for Arduino^® boards across various architectures.

Blocks

External Interrupt	Trigger the downstream function-call subsystem from an Interrupt Service Routine
Hardware Interrupt SAMD	Trigger downstream function-call subsystems from interrupt service routine for Arduino SAMD21 core (Since R2023b)
Hardware Interrupt AVR	Trigger downstream function-call subsystems from interrupt service routine for Arduino AVR core (Since R2024a)
Hardware Interrupt SAM	Trigger downstream function-call subsystems from interrupt service routine for Arduino SAM core (Since R2024b)
Hardware Interrupt Teensy4	Trigger downstream function-call subsystems from interrupt service routine for Teensy 4.0 and 4.1 Arduino compatible boards (Since R2024b)

Model Settings

Model Configuration Parameters for Simulink Support Package for Arduino Hardware

Troubleshooting

Workaround for Interrupt Workflow with Sensors

Follow the steps to use interrupts with sensors and the I2C protocol.

External Interrupts Workflow for Arduino

Follow the steps to use external interrupts in Simulink models.

Featured Examples

Generate Interrupts Using Arduino SAMD PWM Block

Use the Hardware Interrupt block to create an interrupt service routine (ISR) to react to the PWM events on your Arduino® hardware.

Open Model

Get Started with Arduino SAMD Event System Using PWM and ADC Peripherals

Use the event system with Arduino Advanced PWM, Analog Input, and Hardware Interrupt blocks.

Open Model

Estimate Battery Current of PMSM in Open-Loop Control Using Arduino Hardware

Use Simulink® Support Package for Arduino® Hardware to estimate the battery current of a permanent magnet synchronous machine (PMSM) in open-loop control using Motor Control Blockset™. This example also shows how to actuate a PMSM motor and calculate phase currents that are indirectly used to estimate the current of the battery.

Open Model

Trigger Downstream Function-Call Subsystem Using Arduino External Interrupt Block

Trigger a downstream function call subsystem by using an External Interrupt block from the Simulink® Support Package for Arduino® Hardware.

Open Model

Measure PWM Frequency by Triggering an ISR on Arduino Hardware

Measure the frequency of a pulse-width modulation (PWM) signal on an Arduino® hardware using Arduino External Interrupt block. The example uses the same board to generate and detect the PWM signal. The pin 2 is connected to the pin 3 of the Arduino Mega 2560 hardware. The pin 2 generates PWM signal. When there is a rising edge at pin 3, the External Interrupt block executes a function call to calculate the time between two consecutive rising edges of the signal, which in turn is used to calculate the frequency of the signal at pin 3.

Open Model

Read Data from ICM20948 Sensor Using Data Ready Interrupt

Use the interrupt generated by ICM20948 IMU Sensor block to trigger a downstream function-call subsystem that reads acceleration and angular velocity data from the ICM-20948 sensor connected to an Arduino® board.

Open Model

Triple-Axis Tilt Calculation Using LIS3DH FIFO Data Ready Interrupt

Use the FIFO data ready interrupt of LIS3DH linear accelerometer connected to an Arduino® board to sense the tilt of the sensor. This is done using a downstream function-call subsystem that reads acceleration values from FIFO buffer sensor.

Open Model

Single Click and Double Click Detection Using LIS3DH Single Click Interrupt

Use the Single Click interrupt of LIS3DH linear accelerometer connected to an Arduino® board to sense the single click and double click of the sensor.

Open Model

Free-Fall Detection Using LIS3DH Freefall Application Interrupt

Use the Inertial freefall application interrupt of LIS3DH linear accelerometer connected to an Arduino® board to sense the free-fall of the sensor.

Open Model

Impact Detection Using LIS3DH Inertial Wakeup Interrupt

Use the Inertial wake-up interrupt of LIS3DH linear accelerometer connected to an Arduino® board to sense the impact of the sensor.

Open Model
