traceStep
Description
Use the traceStep
object to create a step trace in the
XY plane.
Creation
Description
trace = traceStep
creates a step trace in the
XY plane.
trace = traceStep(
sets Properties using one or more
name-value arguments. For example, Name=Value
)traceStep(ReferencePoint=[1 1])
creates a step trace with the reference point [1 1]
. Properties not
specified retain their default values.
Properties
Object Functions
add | Boolean unite operation on two RF PCB shapes |
subtract | Boolean subtraction operation on two RF PCB shapes |
intersect | Boolean intersection operation on two RF PCB shapes |
plus | Shape1 + Shape2 for RF PCB shapes |
minus | Shape1 - Shape2 for RF PCB shapes |
mirrorX | Mirror shape along X-axis |
mirrorY | Mirror shape along Y-axis |
and | Shape1 & Shape2 for RF PCB shapes |
area | Calculate area of RF PCB shape in square meters |
rotate | Rotate RF PCB shape about defined axis |
rotateX | Rotate RF PCB shape about x-axis |
rotateY | Rotate RF PCB shape about y-axis and angle |
rotateZ | Rotate RF PCB shape about z-axis |
translate | Move RF PCB shape to new location |
scale | Change size of RF PCB shape by fixed amount |
Examples
Version History
Introduced in R2022a
See Also
traceLine
| traceCross
| traceRectangular
| tracePoint
| traceSpiral
