# angl2str

Convert angles to character array

## Syntax

```str = angl2str(angle) str = angl2str(angle,signcode) str = angl2str(angle,signcode,units) str = angl2str(angle,signcode,units,n) ```

## Description

`str = angl2str(angle)` converts a numerical vector of angles in degrees to a character array. The purpose of this function is to make angular-valued variables into character vectors suitable for map display.

`str = angl2str(angle,signcode)` specifies the method for indicating that a given angle is positive or negative, where `signcode` is one of the following:

 `'ew'` east/west notation; trailing 'e' (positive longitudes) or 'w' (negative longitudes) `'ns'` north/south notation; trailing 'n' (positive latitudes) or 's' (negative latitudes) `'pm'` plus/minus notation; leading '+' (positive angles) or '-' (negative angles) `'none'` blank/minus notation; leading '-' for negative angles or sign omitted for positive angles (the default value)

`str = angl2str(angle,signcode,units)` specifies the units and the output format of the returned angle, using the following values:

UnitsUnits of AngleOutput Format
`'degrees'`degreesdecimal degrees
`'degrees2dm'`degreesdegrees + decimal minutes
`'degrees2dms'`degreesdegrees + minutes + decimal seconds
`'radians'`radiansdecimal radians

`str = angl2str(angle,signcode,units,n)` uses the integer `n` to control the number of significant digits provided in the output. `n` is the power of 10 representing the last place of significance in the number of degrees, minutes, seconds, or radians -- for `units` of `'degrees`', `'degrees2dm'`, `'degrees2dms'`, and `'radians'`, respectively. For example, if ```n = -2``` (the default), `angl2str` rounds to the nearest hundredth. If `n = -0`, `angl2str` rounds to the nearest integer. And if `n = 1`, `angl2str` rounds to the tens place, although positive values of `n` are of little practical use. Note that this sign convention for `n` is opposite to the one used by the MATLAB® `round` function.

## Examples

collapse all

Create a series of values for angles.

`a = -3:1.5:3;`

Convert the numeric values in DMS units, using the north-south format.

`str = angl2str(a,'ns','degrees2dms',-3)`
```str = 5x25 char array ' 3^{\circ} 00' 00.000" S ' ' 1^{\circ} 30' 00.000" S ' ' 0^{\circ} 00' 00.000" ' ' 1^{\circ} 30' 00.000" N ' ' 3^{\circ} 00' 00.000" N ' ```

These LaTeX strings are displayed (using the `text` function) as follows:

```x = [.1 .1 .1 .1 .1]; y = [.1 .2 .3 .4 .5]; text(x,y,str)```
