Quick-Control Interfaces
Communicate with IVI-C-based instruments using Quick-Control
Oscilloscope, Function Generator, and RF Signal Generator
The Quick-Control interfaces are used to control oscilloscopes, function generators, or RF signal generators that use an underlying IVI-C driver. You do not have to deal directly with the driver in these easy-to-use interfaces.
Functions
oscilloscope | Connection to Quick-Control Oscilloscope instrument |
fgen | Connection to Quick-Control Function Generator instrument |
rfsiggen | Connection to Quick-Control RF Signal Generator instrument |
readWaveform | Returns waveform displayed on scope |
configureChannel | Return or set specified oscilloscope control on selected channel |
download | Downloads arbitrary waveform to RF signal generator |
start | Enables RF signal generator signal output and modulation output |
resources | List of available instrument resources for Quick-Control interfaces |
drivers | List of available instrument drivers for Quick-Control interfaces |
connect | Connect device object to instrument |
disconnect | Disconnect device object from instrument |
Topics
Quick-Control Oscilloscope
- Quick-Control Oscilloscope Requirements
You can use the Quick-Control Oscilloscope for any oscilloscope that uses an underlying IVI-C driver. - Read Waveforms Using the Quick-Control Oscilloscope
This example shows the general workflow to use for the Quick-Control Oscilloscope. - Read a Waveform Using a Tektronix Scope
Reading a waveform with a Tektronix® scope using Quick-Control Oscilloscope is basically the same workflow as described in the Read Waveforms Using Quick-Control Oscilloscope example using a Keysight® scope with VISA. - Quick-Control Oscilloscope Functions
Theoscilloscope
function can use the following special functions, in addition to standard functions such asconnect
anddisconnect
. - Quick-Control Oscilloscope Properties
The Quick-Control Oscilloscopeoscilloscope
function can use the following properties.
Quick-Control Function Generator
- Quick-Control Function Generator Requirements
You can use the Quick-Control Function Generator for simplified fgen control and waveform generation without having to directly deal with the underlying driver. - Generate Standard Waveforms Using the Quick-Control Function Generator
Use the Quick-Control Function Generator to generate a standard waveform. - Generate Arbitrary Waveforms Using Quick-Control Function Generator
Use the Quick-Control Function Generator to generate an arbitrary waveform. - Quick-Control Function Generator Functions
Thefgen
function uses the following functions, in addition to standard functions such asconnect
anddisconnect
. - Quick-Control Function Generator Properties
Thefgen
function can use the following properties.
Quick-Control RF Signal Generator
- Quick-Control RF Signal Generator Requirements
You can use the Quick-Control RF Signal Generator for simplified rfsiggen control and waveform generation without having to directly deal with the underlying driver. - Quick-Control RF Signal Generator Functions
Therfsiggen
function uses the following functions. - Quick-Control RF Signal Generator Properties
Therfsiggen
function uses the following properties. - Download and Generate Signals with RF Signal Generator
These examples show how to create therfsiggen
object, download waveforms, and generate signal and modulation output.
Troubleshooting
Troubleshooting IVI and Quick-Control Interfaces
Try these tips if you have problems using the toolbox with the IVI and Quick-Control interfaces. Includes information about supported platforms, adaptor requirements, configuration and connection, and other interface-specific tips.
