## Multivariate Time Series Model Creation

### Models for Multiple Time Series

Econometrics Toolbox™ VAR model functions require a `varm` model object as an input before they simulate, estimate, forecast, or perform other calculations. `varm` model objects specify the structure of the VAR model, that is, the number of response series, number of lags, whether there are constants or time trends in the response equations, etc. `varm` model can serve as a model template for estimation, or you can specify known values for some or all parameters either during model creation or after using dot notation.

By default, `varm` sets unknown parameter values to `NaN` based on its specified structure. `NaN` values in model properties indicate that the parameter is present, but the value is unknown and needs fitting to data. Although, time series data motivates model creation, it is not required to create a model. If you have data, you can fit models to the data as described in VAR Model Estimation. If you do not have data, you can create a fully-specified model, that is, you provide all parameter values, as described in Model Objects with Known Parameters.

### Creating VAR Models

Create an Econometrics Toolbox VAR model object using `varm`. Use this object for estimating, simulating, forecasting, and analyzing multiple time series.

There are two syntaxes for `varm` model object creation: shorthand and longhand. The shorthand syntax is suited for the quick creation of a model that has all unknown parameters. Using the shorthand syntax, you create a model template for estimation that specifies the dimension of the response variable (`numseries`), the degree of the VAR model (`p`), and that the AR polynomial has nonzero lags 1 through `p`. After creating a model this way, you can change some parameter values by adjusting property values using dot notation (see Displaying and Changing Model Objects). For an example, see Create and Adjust VAR Model Using Shorthand Syntax.

The longhand syntax allows for more flexibility in parameter specification than the shorthand syntax. For example, you can specify values of autoregressive coefficient matrices or which lags have nonzero coefficient matrices. Whereas `varm` requires the dimensionality of the response variable and degree of the VAR model when you use the shorthand syntax, `varm` infers these structural characteristics from the arguments you supply when you use the longhand syntax. For an example, see Create and Adjust VAR Model Using Longhand Syntax.

Independent of syntax preference, there are several ways to create model objects using `varm`, and they depend on your analysis goal.

• Model Objects with Known Parameters. Use this method when you know the values of all relevant parameters of your model. That is, you do not plan to fit the model to data.

• Model Objects with No Parameter Values. Use this method when you know the size, type, and number of lags in your model, but do not know, for example, the values of any of the AR coefficient matrices or the value of the innovations covariance. That is, you know the structure of the VAR model, and you want to fit the model to data using `estimate`.

• Model Objects with Selected Parameter Values. Use this method when you know the size, type, and number of lags in your model, and also know some, but not all, of the parameter values. For example, you know the values of some of the AR coefficient matrices. To estimate any unknown parameter values, you pass the model object and data to `estimate`, which applies equality constraints to all known parameters at their values and estimates the rest.

### Create and Adjust VAR Model Using Shorthand Syntax

This example shows how to create a three-dimensional VAR(4) model with unknown parameters using `varm` and the shorthand syntax. Then, this example shows how to adjust parameters of the created model using dot notation.

Create a VAR(4) model for a three-dimensional response series using the shorthand syntax.

```numseries = 3; p = 4; Mdl = varm(3,4)```
```Mdl = varm with properties: Description: "3-Dimensional VAR(4) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 4 Constant: [3×1 vector of NaNs] AR: {3×3 matrices of NaNs} at lags [1 2 3 ... and 1 more] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```

`Mdl` is a `varm` model object. The properties of the model display at the command line. Observe that:

• The default value of some of the parameters are `NaN` values, which indicates their presence in the model. In particular, each lag from 1 through 4 has an unknown, nonzero autoregressive coefficient matrix.

• You created the model without using response data. That is, `Mdl` is agnostic about data.

Suppose that you want lags 1 and 4 in the model to be unknown and nonzero, but all other lags are zero. Using dot notation, remove the other lags from the model object by placing 3-by-3 matrices of zeros the corresponding cells.

```Mdl.AR{2} = zeros(3); Mdl.AR{3} = zeros(3)```
```Mdl = varm with properties: Description: "3-Dimensional VAR(4) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 4 Constant: [3×1 vector of NaNs] AR: {3×3 matrices} at lags [1 4] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```

Observe that the model degree `p` is still `4`, but there are unknown, nonzero coefficients at lags 1 and 4 only.

### Create and Adjust VAR Model Using Longhand Syntax

This example shows how to create a three-dimensional VAR(4) model with unknown parameters using `varm` and the longhand syntax. Then, this example shows how to adjust parameters of the created model using dot notation.

Create a VAR(4) model for a three-dimensional response series. Specify that there are unknown coefficient matrices at lags 1 and 4 only.

```numseries = 3; p = 4; ar = {nan(3) nan(3)}; lags = [1 p]; Mdl = varm('AR',ar,'Lags',lags)```
```Mdl = varm with properties: Description: "3-Dimensional VAR(4) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 4 Constant: [3×1 vector of NaNs] AR: {3×3 matrices} at lags [1 4] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```

`Mdl` is a `varm` model object. The properties of the model display at the command line. Observe that:

• The default value of some of the parameters are `NaN` values, which indicates their presence in the model.

• You created the model without using response data. That is, `Mdl` is agnostic about data.

Suppose that you want to add a linear time trend to the model to be estimated. By default, the linear time trend is zero. To make an unknown time trend present in the model, set the `Trend` property to a 3-by-1 vector of `NaN` values using dot notation.

`Mdl.Trend = nan(3,1)`
```Mdl = varm with properties: Description: "3-Dimensional VAR(4) Model with Linear Time Trend" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 4 Constant: [3×1 vector of NaNs] AR: {3×3 matrices} at lags [1 4] Trend: [3×1 vector of NaNs] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```

### Model Objects with Known Parameters

If you know the values of model parameters, create a model object with the parameter values using longhand syntax. The following are the name-value pair arguments you can pass to `varm` for known parameter values in a `numseries`-dimensional VAR(`p`) model:

Model Parameters

NameValue
`Constant`

A `numseries`-vector of model constants or intercepts. The default is a `NaN` vector.

`Lags`

A numeric vector of autoregressive polynomial lags. The largest lag determines `p`, the degree of the VAR model. If you specify `Lags`, then each element corresponds to the elements of `AR`. The default is value is `1:p`.

`AR`

A cell vector of `numseries`-by-`numseries` AR coefficient matrices. Cells correspond to the elements of `Lags`. By default, all cells contain matrices composed of `NaN` values.

`Trend`

A `numseries`-vector of linear time trends. The default is a vector of zeros.

`Beta`

A `numseries`-by-`numpreds` matrix of regression coefficients. The default is empty, that is, no regression component exists in the model.

`Covariance`

A `numseries`-by-`numseries` symmetric, positive definite innovations covariance matrix. The default is a matrix composed of `NaN` values.

Alternatively, you can create a model object using shorthand syntax, and then adjust corresponding property values using dot notation (with the exception of `Lags`).

The `Lags` vector allows you to specify which lags you want to include. For example, to specify AR lags 1 and 3 without lag 2, set `Lag` to `[1 3]`. Although there are only two lags, `p` is `3`.

The following example shows how to create a model object when you have known parameters. Consider the VAR(1) model

`${y}_{t}=\left[\begin{array}{c}0.05\\ 0\\ -0.05\end{array}\right]+\left[\begin{array}{ccc}0.5& 0& 0\\ 0.1& 0.1& 0.3\\ 0& 0.2& 0.3\end{array}\right]{y}_{t-1}+{\epsilon }_{t}.$`

The independent disturbances εt are distributed as standard three-dimensional normal random variables.

Create a model object with `varm`:

```c = [0.05; 0; -0.05]; ar = {[.5 0 0;.1 .1 .3;0 .2 .3]}; Covariance = eye(3); Mdl = varm('Constant',c,'AR',ar,'Covariance',Covariance)```
```Mdl = varm with properties: Description: "AR-Stationary 3-Dimensional VAR(1) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 1 Constant: [0.05 0 -0.05]' AR: {3×3 matrix} at lag [1] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 diagonal matrix] ```

`varm` identifies this model as a stationary VAR(1) model with three dimensions, additive constants, no time trend, and no regression component.

### Model Objects with No Parameter Values

By default, `estimate` fits all unspecified (that is, elements containing `NaN` values) model constants, autoregressive coefficient matrices, regression coefficients, linear time trends, and the innovation covariance matrix. You must specify pass a `varm` model object containing unknown values and the data to `estimate` to fit the unknown parameters.

This example shows how to specify the model in Model Objects with Known Parameters, but without explicit parameters.

`Mdl = varm(3,1)`
```Mdl = varm with properties: Description: "3-Dimensional VAR(1) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 1 Constant: [3×1 vector of NaNs] AR: {3×3 matrix of NaNs} at lag [1] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```

### Model Objects with Selected Parameter Values

You can create a model object with some known parameters, and have `estimate` fit the unknown parameters to data. `estimate` honors all equality constraints except for those in the innovation covariance matrix, that is, the innovations covariance must be completely composed of `NaN` values for estimation.

This example shows how to specify the model in Model Objects with Known Parameters, but with requested AR parameters with a diagonal autoregressive structure and an unknown innovation covariance. `varm` infers the dimensionality of the response variable from the parameters `c` and `AR` and the degree of the VAR model from `AR`.

```c = [.05; 0; -.05]; ar = {diag(nan(3,1))}; Mdl = varm('Constant',c,'AR',ar)```
```Mdl = varm with properties: Description: "3-Dimensional VAR(1) Model" SeriesNames: "Y1" "Y2" "Y3" NumSeries: 3 P: 1 Constant: [0.05 0 -0.05]' AR: {3×3 matrix} at lag [1] Trend: [3×1 vector of zeros] Beta: [3×0 matrix] Covariance: [3×3 matrix of NaNs] ```
`Mdl.AR{:}`
```ans = 3×3 NaN 0 0 0 NaN 0 0 0 NaN ```

### Displaying and Changing Model Objects

After you set up a model object, you can examine it in several ways:

• Enter `Mdl` at the MATLAB® command line, where `Mdl` is the name of the model structure.

• Double-click the object in the MATLAB Workspace browser.

• Enter `Mdl.PropertyName` at the MATLAB command line, where `Mdl` is the name of the model object, and `PropertyName` is the name of the property you want to examine or reassign.

You can change any writable part of a model object named, for example, `Mdl`, using dot notation as follows:

`Mdl.PropertyValue = value;`

This syntax changes only the `PropertyValue` parts `Mdl`.

### Determining an Appropriate Number of Lags

There are two Econometrics Toolbox functions that can help you determine an appropriate number of lags for your models:

• `lratiotest` performs likelihood ratio tests to help identify the appropriate number of lags.

• `aicbic` calculates the Akaike and Bayesian information criteria (AIC and BIC, respectively) to determine the minimal appropriate number of required lags.

#### Example: Using the Likelihood Ratio Test to Calculate the Minimal Requisite Lag

`lratiotest` requires inputs of the loglikelihood of an unrestricted model, the loglikelihood of a restricted model, and the number of degrees of freedom (DoF). DoF is the difference in the number of active parameters between the unrestricted and restricted models. `lratiotest` returns a Boolean: `1` means reject the restricted model in favor of the unrestricted model, `0` means there is insufficient evidence to reject the restricted model.

In the context of determining an appropriate number of lags, the restricted model has fewer lags, and the unrestricted model has more lags. Otherwise, test models with the same type of fitted parameters.

• Obtain the loglikelihood (`logL`) of a model as the third output of `estimate`:

`[EstMdl,EstSE,logL,E] = estimate(...)`
• Obtain the number of active parameters in a model (`numParameters`) from the `NumEstimatedParameters` field in the output structure of `summarize`:

```results = summarize(EstMdl); numParameters = results.NumEstimatedParameters;```

For example, suppose you have four fitted models with varying lag structures. The models have loglikelihoods `logL1`, `logL2`, `logL3`, and `logL4`, and active parameter counts `n1p`, `n2p`, `n3p`, and `n4p`. Suppose model 4 has the largest number of lags. Perform likelihood ratio tests of models 1, 2, and 3 against model 4, as follows:

```reject1 = lratiotest(logL4,logL1,n4p - n1p) reject2 = lratiotest(logL4,logL2,n4p - n2p) reject3 = lratiotest(logL4,logL3,n4p - n3p)```

If `reject1` = `1`, you reject model 1 in favor of model 4, and similarly for models 2 and 3. If any of the models have `rejectI` = `0`, you have an indication that you can use fewer lags than in model 4.

#### Example: Using Akaike Information Criterion to Calculate the Minimal Requisite Lag

You can obtain the AIC and BIC fit statistics two ways:

• Passing an estimated model to `summarize`, and extracting the desired fit statistic from the output structure.

• Estimate a model using `estimate`:

`EstMdl = estimate(...);`
• Obtain the AIC and BIC of the estimated model from the `AIC` and `BIC` fields in the output structure of `summarize`:

```results = summarize(EstMdl); aic = results.AIC; bic = results.BIC;```
• Using `aicbic`. `aicbic` requires inputs of the loglikelihood of a model and of the number of active parameters in the model. `aicbic` also accepts vectors of loglikelihoods and vectors of active parameters, which makes it easy to compare multiple model fits.

Lower values of these information criteria indicate better fits to the data.

• Obtain the loglikelihood (`logL`) of a model as the third output of `estimate`:

`[EstMdl,EstSE,logL,E] = estimate(...)`
• Obtain the number of active parameters in a model (`numParameters`) from the `NumEstimatedParameters` field in the output structure of `summarize`:

```results = summarize(EstMdl); numParameters = results.NumEstimatedParameters;```

For example, suppose you have four fitted models with varying lag structures. The models have loglikelihoods `logL1`, `logL2`, `logL3`, and `logL4`, and active parameter counts `n1p`, `n2p`, `n3p`, and `n4p`. Calculate the Akaike information criteria as follows:

`AIC = aicbic([logL1 logL2 logL3 logL4],[n1p n2p n3p n4p])`

The most suitable model has the lowest value of the Akaike information criterion.
