Power Conversion
R2026bBuild and deploy power conversion applications on STM32 processors in
STM32™
Microcontroller Blockset
Explore power conversion examples that illustrate DC-DC converter and PFC (power factor conversion) capabilities.
Topics
- STM32CubeMX Configuration for Voltage Mode Control
Configure STM32CubeMX peripheral settings for voltage-mode motor control on an STM32 processor.
- Set Up Scheduling Options for STM32 Processor-Based Boards
Configure single-rate or multi-rate scheduling on an STM32 processor.
Featured Examples
Voltage Mode Control of DC-DC Buck Converter and Boost Converter Using STMicroelectronics STM32 Processor
Implement a DC-DC buck converter or Boost Converter control system using the B-G474E-DPOW1 Discovery kit for STM32™ Microcontroller Blockset.
Using Hardware Interrupt Block to Create an ISR on STMicroelectronics STM32 Processor Based Boards
Use a Hardware Interrupt block to create an interrupt service routine (ISR) in the generated code for STM32™ Microcontroller Blockset.
Totem-Pole Boost PFC With Inrush Current Limiter
Model, simulate, and deploy a digital control algorithm for a totem-pole power factor correction (PFC) converter with an inrush current limiter (ICL).
