Pulse and Transition Metrics

Rise time, fall time, slew rate, overshoot, undershoot, settling time, pulse width, duty cycle

Compute metrics related to pulses and transitions. Measure rise time, fall time, slew rate, overshoot, undershoot, settling time, pulse width, pulse period, and duty cycle.

Functions

expand all

dutycycle Duty cycle of pulse waveform
midcrossMid-reference level crossing for bilevel waveform
pulseperiodPeriod of bilevel pulse
pulsesepSeparation between bilevel waveform pulses
pulsewidthBilevel waveform pulse width
statelevels State-level estimation for bilevel waveform with histogram method
falltime Fall time of negative-going bilevel waveform transitions
overshoot Overshoot metrics of bilevel waveform transitions
risetime Rise time of positive-going bilevel waveform transitions
settlingtimeSettling time for bilevel waveform
slewrateSlew rate of bilevel waveform
undershoot Undershoot metrics of bilevel waveform transitions

Topics

Estimate State for Digital Clock

Estimate the high and low state levels for data from a digital clock.
