appdesigner

Open App Designer Start Page or existing app file

Description

example

appdesigner opens the App Designer Start Page. From the Start Page you can create a new blank app, or a new 2-panel or 3-panel app with auto-reflow, or you can:

  • View a list of your most recently used apps.

  • Explore featured examples to help you get started.

  • Take a guided tutorial to learn the basics of App Designer.

  • Discover new App Designer features highlighted in the carousel.

example

appdesigner(filename) opens the specified .mlapp file in App Designer. If the .mlapp file is not on the MATLAB path, specify the full path.

Examples

collapse all

Create a new app that automatically resizes and reflows content to respond to different device screen sizes.

Open the App Designer Start Page.

appdesigner

Select one of the preconfigured apps with auto-reflow from the Start Page. A new file titled app1.mlapp opens in App Designer. The app1.mlapp file does not appear in the MATLAB® Current Folder browser until you save it.

Open and display an existing app file from your MATLAB search path.

appdesigner("mortgage")

Input Arguments

collapse all

Name or path of an app file, specified as a character vector or string scalar. Including .mlapp in the file name is optional. Only one file name can be passed into the appdesigner function at time.

If filename appears in multiple folders on the search path, then include a path to the file. The file specification must be the complete or relative path to a file, or the name of a file on the MATLAB path.

Example: appdesigner('app1.mlapp')

Example: appdesigner("app1")

Example: appdesigner("C:\Documents\Data\watertables.mlapp")

Tips

You can also create or edit apps using the App Designer development environment in MATLAB Online™ (supported only for Google Chrome™ browsers).

Introduced in R2016a
