Image Segmenter

Segment an image by refining regions

Description

The Image Segmenter app lets you segment an image using the active contours (also called snakes) algorithm. Using this app, you first create an initial segmentation that defines seed locations and then segment the image iteratively.

Open the Image Segmenter App

  • MATLAB® Toolstrip: Open the Apps tab, under Image Processing and Computer Vision, click the Image Segmenter app icon.

  • MATLAB command prompt: Enter imageSegmenter.

Programmatic Use

expand all

imageSegmenter opens the Image Segmenter app, which enables you to create a segmentation mask of an image by using active contours.

imageSegmenter(I) opens the Image Segmenter app, loading the image I into the app.

imageSegmenter close closes all open instances of the Image Segmenter app.

Introduced in R2014b
