Microchip FPGA and SoC Devices

Generate and deploy HDL code and embedded software on Microchip SoC Devices

HDL Coder™ can generate an IP core, integrate it into your Libero^® project, and program the Microchip hardware.

To deploy your design to the Microchip FPGA and SoC device, you must install the HDL Coder Support Package for Microchip FPGA and SoC Devices. For installation information, see HDL Coder Supported Hardware.

Classes

expand all

Board and Workflow

`hdlcoder.Board`	Board registration object that describes SoC custom board
`hdlcoder.WorkflowConfig`	Configure HDL code generation and deployment workflows
`hdlcoder.ReferenceDesign`	Reference design registration object that describes SoC reference design

Functions

expand all

Add Interfaces

`addExternalIOInterface`	Define external IO interface for board object
`addExternalPortInterface`	Define external port interface for board object
`addInternalIOInterface`	Add and define internal IO interface between generated IP core and existing IP cores
`addAXI4SlaveInterface`	Add and define AXI4 slave interface
`addClockInterface`	Add clock and reset interface

Board and Reference Design

`addCustomLiberoDesign`	Specify Microchip Libero SoC exported block design Tcl file
`addCustomMSSConfig`	Import microcontroller subsystem (MSS) in Microchip Libero Smart design
`validateReferenceDesign`	Check property values in reference design object
`validateBoard`	Check property values in board object

Related Information

Featured Examples

Integrate HDL IP Core with Microchip PolarFire SoC Icicle Kit Reference Design

Use the hardware-software co-design workflow to blink LEDs at various frequencies on the Microchip PolarFire SoC Icicle kit.

Open Script

Generate Board-Independent HDL IP Core for Microchip Platforms

Generate an HDL IP core for a generic Microchip platform. You generate an HDL IP core for an LED blinking model, then integrate this HDL IP core into a target Microchip platform of your choice. You can generate a board-independent custom IP core to use in an embedded system integration environment, such as Microchip Libero SoC tool.

Open Script

Define Custom Board and Reference Design for Microchip Workflow

Define and register a custom board and reference design for a blinking LED model in the Microchip workflow of the HDL Workflow Advisor. You use a SmartFusion2® board, but you can define and register a custom board or a custom reference design for other Microchip platforms.

Open Script

Define Custom Board and Reference Design for Microchip Pure FPGA Platforms

Define and register a Pure FPGA boards and reference design for a LED blinking model in the IP Core Generation workflow of the HDL Workflow Advisor. You use a Microchip PolarFire® board, but you can define and register a custom board or a custom reference design for other Microchip platforms.

Open Script
